How To Take Apart Xbox One Controller?

Before you start taking apart your Xbox One controller, make sure you have a clean and well-lit workspace. This blog post will show you how to take apart the Xbox One Controller. We will thoroughly explain the process, including possible issues and the tools you might need. Even though Xbox One controllers are considered good, they can still have problems and need fixing sometimes. Get a T-8 safety Torx and a prying tool if you don’t have them already. So, here’s a simple guide:

  • Use the prying tool to separate one of the grip covers gently.
  • Once it starts to come off, finish pulling it off by hand.
  • Do the same for the other grip cover.
  • Remove the battery cover.
  • Now, it’s time to take out the screws.
  • Begin with the hidden screw inside the battery compartment, using the T-8 safety Torx bit.
  • Be careful not to strip the screw by properly seating the bit and applying even pressure.
  • Use the same Torx bit to remove one screw from one grip, and then remove the second screw from the same grip.
  • Repeat this process for the other grip, and the controller will collapse.
  • You’ll now have access to the rumble motors, triggers, and some other screws.
  • Leave these alone unless you need to replace specific components on the circuit board. Remove the assembly from the front case and flip it around to access most other components.

Fix Your Xbox One Controller

For some fixes, like soldering, you might need advanced skills. After disassembling your Xbox One controller, you can try to fix it. Clean solves some issues, but others may need you to replace parts. If you’re not confident, it’s best to let experts handle those repairs.

Continue Reading: How Long Does Xbox Update Take?

Summing Up

The Xbox One controller isn’t just good for gaming. You can also disassemble and repair it manually. This manual will assist you in easily taking apart and reassembling your Xbox One controller. Gently remove the grip covers, take out the battery cover, and use a Torx bit to unscrew hidden and grip screws. This will allow you to access and replace various parts if needed. Besides, how to take apart Xbox One Controller you should have some basic knowledge about its parts. The controller has three main sections, the front cover, the main body containing the circuits, and the back cover with the battery compartment.
